The extra power of E-bikes asks for extra strong parts. E-bike rims like the 535 are single eyeletted and feature a wide, reinforced profile. This ensures they are long lasting and perfectly compatible with higher volume tires.
Features:
System weight:
– The system weight is composed of the weight of the rider and his equipment, plus the bike with luggage.
Rim Diameter:
– The 700c (622 mm / 29 inches) is the most common wheel size for road racing. The 650b (584 mm / 27.5 inches) wheel size is used in specific areas. Each wheel size offers unique advantages for different kinds of riding.
Rim height:
– In cycling, rim height significantly impacts the aerodynamics, agility and weight of the wheel. The general principle is the higher the profile of the rim, the greater the aerodynamic advantage; the lower the profile of the rim, the greater the response and better the handling when cornering and changing speed.
Rim Inner Width:
– DT Swiss offers MTB rims with inner rim widths of 20 – 76 mm. The right combination of tire width and rim width leads to ideal tire support. Better tire support reduces the risk of ´´burping´´ and therefore allows the tire pressure to be reduced. On the other hand, wider rims and wider tires also increase the weight of the wheels.
Brake Interface:
– The advantage of the Center Lock system is that the disc brake attachment is made with one single lock ring, which facilitates assembly. On the other hand, an advantage of the IS-System (6 Bolt) is that in the event of a necessary repair on the trail, no special tool is needed for disassembly.
Pin joint:
– Pin joint refers to a method used in making rims. In this case, the profile ends of the rim are connected using two steel pins. These pins are pressed down flush into the profile ends and ensure a stable connection.
Hooked / Crotchet tube type:
– A tube type rim is designed for the use of a tube between the rim and the tire. The rim flanges have so-called hooks. This supports the fixation of the tire bead and ensures safe function, also in high pressure use cases (>5 bar tire pressure).
Specifications:
General:
– Net weight: 540 g
– Recommended System weight max.: 140 kg
– ASTM classification: 2
Material & Brake Interface:
– Material: Aluminium
– Rim joint: Pin joint
– Tire interface: Hooked / Crotchet tube type
– Brake Interface: Non disc
Dimensions:
– Rim Diameter: 26´´
– Reference diameter ERD: 540 mm
– Inner Width: 19 mm
– Outer width: 24 mm
– Rim Height: 20 mm
Holes:
– Number of holes: 32
– Spoke bore rim: Silver eyelet
– Valve hole: Schrader (plus Presta-adapter)
Inclusive:
– Valve adapter AV to SV
Color: Silver
Recommended Use: Urban Cycling
Product Type: Rims
